BQLZR Microwave Oven Door Switch Normally Open and Close 5E4 16A 125V 250V

Features:
1.Every product has a unique Manufacturing Part Number label on the inner package that proves it has been qualified,which include Part Number,Model Number and inspection date information;
2.If you have any questions about the item,please provide us the Manufacturing Part Number for checking,your profits will be guaranteed.
3.Compatible models:
Replacement for SZM-V16-FD-63, Replacement for 3B73362F,
Replacement for SZM-V16-FA-63, Replacement for PS3522738.
4.Normally Open Switch: After pressing the switch button, the internal contact is closed and the switch is in on state.
5.Normally Closed Switch: After pressing the switch button, the internal contacts are separated and the switch is disconnected.
6.The microwave door switch is compatible with most microwave ovens. If the microwave oven cannot rotate or heat normally, the door switch may have problems. The new switch can restore the microwave oven to normal work.
7.Made of high-quality metal and plastic, excellent touch switch, good touch effect and long service life.

Specifications:
Material: Plastic & Metal
Color: Black
Brand name: BQLZR
Size: 38x21x10mm/1.50"x0.83"x0.39"(L x W x H)
Shell Dimensions: 27.8 x 15.9 x 10.3 mm/1.09" x 0.63"x 0.41".
Weight: 21g （4pcs）
Current: 16A
Voltage: 125V & 250V
Mechanical Life: 5E4 (50000 times)
Insulation strength: 100MΩ Min
Test voltage: AC1000V/2000V
Contact resistance: 50mΩ Max
Operating force: 1.5N Max
Releasing force: 0.3N Min
Operating position: 14.7±0.4mm
Movement error: 0.4mm Max.
